The Centerforce(R) DFX(R) Clutch Series is SFI approved and brings together various reinforcements and patenteds technologies for a great race-inspired single disc clutch.
this can cause some additional drive train noise and/or chatter.
Application Summary:
| Year |
Make/Model |
| 2005-2010 |
Dodge Ram 2500 |
| 2005-2010 |
Dodge Ram 3500 |
| 2008-2010 |
Dodge Ram 4500 |
| 2008-2010 |
Dodge Ram 5500 |
| 2011-2018 |
Ram 2500 |
| 2011-2018 |
Ram 3500 |
| 2011-2017 |
Ram 4500 |
| 2011-2016 |
Ram 5500 |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Bolt Pattern |
23, 23 |
| Clutch Disc Diameter |
13, 13, 330.2 |
| Counterweight Assist |
YES, Yes |
| Country of Origin (Primary) |
JP |
| Crankshaft Bolt Hole Quantity |
8, 8, 8 |
| Disc Material |
Cerametallic, Cerametallic |
| Disc Type |
8-Paddle, 8-Paddle |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Flywheel Crank Bolt Size |
12, 12mm, 12 |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Input Shaft Diameter |
1-3/8, 1-3/8 |
| Input Spline Quantity |
10, 10 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Cast Iron Flywheel / Cast Iron Pressure Plate / Cerametallic Friction, Cast Iron Flywheel / Cast Iron Pressure Plate / Cerametallic Friction |
| Mounting Hardware Included |
Yes, Yes |
| NAFTA Preference Criterion Code |
D |
| Outside Diameter |
15.625 |
| Pilot Bushing Included |
Yes, Yes |
| Release Bearing Included |
Yes, Yes |
| Ring Gear O.D |
15.625 |
| Ring Gear O.D. |
15.625, 15.625 |
| Ring Gear OD |
15.625 |
| Ring Gear Tooth Count |
152 |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
Y, Y |
| Tooth Quantity |
152, 152 |
| Torque Capacity |
1100, 1100 |
| Warranty Time |
12 |
| GTIN |
00788442032635 |
