The Centerforce(R) I Clutch Series is designed as a high-quality stock replacement for applications with stock engines or mild power increases from minor bolt-on modifications.
The Centerforce(R) I Clutch Series utilizes a full facing disc with premium friction material and is designed as a high-quality entry-level performance clutch for those in need of a superior stock replacement. Using the Centerforce centrifugal weights (where applicable), the Centerforce Stage 1 clutch system is perfect for applications with stock engines or mild power increases from minor bolt-on modifications. Pressure plate and disc sold separately on some applications. The Torque Figures for Centerforce I Pressure Plates are based and calculated in conjunction with a Centerforce I & II Clutch Disc.
Application Summary:
| Year |
Make/Model |
| 1998-2002 |
Chevrolet Prizm |
| 1990-1997 |
Geo Prizm |
| 1990-1997 |
Toyota Celica |
| 2000-2005 |
Toyota Celica |
| 1989-2008 |
Toyota Corolla |
| 2003-2008 |
Toyota Matrix |
| 1985-1989 |
Toyota MR2 |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| ASIN |
B000CIOP88 |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
8.375, 8.375, 212, 212 |
| Counterweight Assist |
YES, Yes, YES |
| Country of Origin (Primary) |
JP |
| Disc Material |
Organic, Organic |
| Disc Type |
Full face, Full face |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Flywheel Step |
0.018, 0.018 |
| Flywheel Step Type |
STEP |
| Friction Surface Configuration |
STEP |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Pressure Plate, Disc, Alignment tool. |
| Input Shaft Diameter |
15/16, 15/16 |
| Input Spline Quantity |
21, 21 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Cast Iron Pressure Plate / Organic Friction, Cast Iron Pressure Plate / Organic Friction, Cast Iron Pressure Plate / Organic Friction |
| NAFTA Preference Criterion Code |
B |
| Outside Diameter of Friction Surface |
212 |
| Outside Diameter of Friction Surface (Metric) |
212 |
| Outside Diameter of Friction Surface (Standard) |
8-3/8 |
| Replaceable Friction Surface |
N |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
N |
| Spline Diameter and Tooth Count |
15/16"-21 |
| Standard Pack |
1 |
| Torque Capacity |
211, 211, 211 |
| Warranty Time |
12 |
| GTIN |
00788442013313 |
