The Centerforce(R) I Clutch Series is designed as a high-quality stock replacement for applications with stock engines or mild power increases from minor bolt-on modifications.
The Centerforce(R) I Clutch Series utilizes a full facing disc with premium friction material and is designed as a high-quality entry-level performance clutch for those in need of a superior stock replacement. Using the Centerforce centrifugal weights (where applicable), the Centerforce Stage 1 clutch system is perfect for applications with stock engines or mild power increases from minor bolt-on modifications. Pressure plate and disc sold separately on some applications. The Torque Figures for Centerforce I Pressure Plates are based and calculated in conjunction with a Centerforce I & II Clutch Disc.
Application Summary:
| Year |
Make/Model |
| 1982-1983 |
Nissan 200SX |
| 1989-1998 |
Nissan 240SX |
| 1970-1973 |
Nissan 240Z |
| 1974 |
Nissan 260Z |
| 1975-1978 |
Nissan 280Z |
| 1979-1983 |
Nissan 280ZX |
| 1975-1979 |
Nissan 620 |
| 1980-1983 |
Nissan 720 |
| 1981 |
Nissan 810 |
| 1982-1983 |
Nissan Maxima |
| 1987-1988 |
Nissan Van |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| ASIN |
B000CIOPVK |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
8.875, 8.875, 225, 225 |
| Counterweight Assist |
YES, Yes, YES |
| Country of Origin (Primary) |
JP |
| Disc Material |
Organic, Organic, Organic |
| Disc Type |
Full face, Full face, Full face |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Flywheel Step |
0.004, 0.004, 0.004 |
| Flywheel Step Type |
STEP |
| Friction Surface Configuration |
STEP |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Pressure Plate, Disc, Alignment tool. |
| Input Shaft Diameter |
1, 1, 1 |
| Input Spline Quantity |
24, 24, 24 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Cast Iron Pressure Plate / Organic Friction, Cast Iron Pressure Plate / Organic Friction, Cast Iron Pressure Plate / Organic Friction |
| NAFTA Preference Criterion Code |
B |
| Outside Diameter of Friction Surface |
225 |
| Outside Diameter of Friction Surface (Metric) |
225 |
| Outside Diameter of Friction Surface (Standard) |
8-7/8 |
| Replaceable Friction Surface |
N |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
N |
| Spline Diameter and Tooth Count |
1"-24 |
| Standard Pack |
1 |
| Torque Capacity |
233, 233, 233 |
| Warranty Time |
12 |
| GTIN |
00788442014952 |
