Centerforce(R) II Clutch Series utilizes our centrifugal weights and patented machining processes for superb holding power and maximum clutch life.
The Centerforce(R) II Clutch Series utilizes a full facing disc with premium friction material and a pressure plate with centrifugal weights (where applicable). Furthermore, static clamp load is increased via our patented machining processes; this combination allows superb holding power and maximum clutch life, making this clutch ideal for selected street/strip, off-road and towing applications. Pressure plate and disc sold separately on some applications. The Torque Figures for Centerforce II Pressure Plates are based and calculated in conjunction with a Centerforce I & II Clutch Disc.
Application Summary:
| Year |
Make/Model |
| 1971-1982 |
Toyota Corolla |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| ASIN |
B000VU5YZU |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
7.875, 7.875, 200, 200 |
| Counterweight Assist |
YES, Yes, YES |
| Country of Origin (Primary) |
JP |
| Disc Material |
Organic, Organic, Organic |
| Disc Type |
Full face, Full face, Full face |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Flywheel Step |
0.018, 0.018, 0.018 |
| Flywheel Step Type |
STEP |
| Friction Surface Configuration |
STEP |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Pressure Plate, Disc, Alignment tool. |
| Input Shaft Diameter |
15/16, 15/16, 15/16 |
| Input Spline Quantity |
21, 21, 21 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Cast Iron Pressure Plate / Organic Friction, Cast Iron Pressure Plate / Organic Friction, Cast Iron Pressure Plate / Organic Friction |
| NAFTA Preference Criterion Code |
B |
| Outside Diameter of Friction Surface |
200 |
| Outside Diameter of Friction Surface (Metric) |
200 |
| Outside Diameter of Friction Surface (Standard) |
7-7/8 |
| Replaceable Friction Surface |
N |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
N |
| Spline Diameter and Tooth Count |
15/16"-21 |
| Standard Pack |
1 |
| Torque Capacity |
164, 164, 164 |
| Warranty Time |
12 |
| GTIN |
00788442015577 |
