Centerforce(R) brings together high-quality friction materials and patented processes to give you top-of-the-line discs.
The Centerforce(R) Dual Friction(R) Disc Series uses a single disc with patented dual friction technology by distributing pressure plate clamp force evenly over a 360-degree friction-facing on one side of the clutch disc, while the opposing side uses a segmented friction-facing to concentrate clamping pressure and increase clutch holding-capacity. These discs are made for Centerforce Dual Friction pressure plates.
Application Summary:
| Year |
Make/Model |
| 1978-1979 |
Ford Bronco |
| 1968-1975 |
Ford F-100 |
| 1975-1979 |
Ford F-150 |
| 1984 |
Ford F-150 |
| 1968-1987 |
Ford F-250 |
| 1968-1987 |
Ford F-350 |
| Attributes |
| ASIN |
B005DJ6ZZ2 |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
12, 12, 304.8 |
| Country of Origin (Primary) |
TH |
| Disc Material |
Organic/Carbon composite, Organic/Carbon composite, Organic/Carbon Composite |
| Disc Type |
Full face/Segmented face, Full face/Segmented face, Full face/Segmented face |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Disc |
| Input Shaft Diameter |
1-1/16, 1-1/16, 1-1/16 |
| Input Spline Quantity |
10, 10, 10 |
| Inside Diameter of Friction Surface |
6.750, 6.750, 171.5, 6.750 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Full Face and Segmented Organic Friction, Full Face and Segmented Organic Friction, Full Face and Segmented Organic Friction |
| NAFTA Preference Criterion Code |
B |
| Out of Package Weight |
5.28, 5.28 |
| Outside Diameter of Friction Surface (Standard) |
12 |
| SDR Required Flag |
N |
| Spline Diameter and Tooth Count |
1-1/16"-10 |
| Standard Pack |
1 |
| Warranty Time |
12 |
| GTIN |
00788442027693 |
