The Centerforce Dual Friction(R) Clutch Series uses patented technologies for an ultimate pressure plate and disc combination.
The Centerforce(R) Dual Friction(R) Clutch Series is a performance matched pressure plate & disc combination featuring the patented Centerforce centrifugal weight system (where applicable) and specialized machining processes to provide a performance clutch that offers exceptional street characteristics, while offering outstanding holding-capacity and durability. Furthermore, the Centerforce Dual Friction disc has an organic full facing on one side for longevity and an organic segmented facing on the other side providing increased holding capacity. Some applications have the organic segmented facings of both sides. The Dual Friction clutch is engineered for those who are looking for the ultimate in street/strip holding power and performance without sacrificing pedal effort and driver control. While the Dual Friction has been engineered primarily as a street clutch it can be used in mild competition applications.
Application Summary:
| Year |
Make/Model |
| 1998-2002 |
Chevrolet Camaro |
| 2010-2015 |
Chevrolet Camaro |
| 1997-2013 |
Chevrolet Corvette |
| 1998-2002 |
Pontiac Firebird |
| 2004-2006 |
Pontiac GTO |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Bolt Pattern |
14, 14 |
| Clutch Disc Diameter |
12, 12, 12, 304.8 |
| Counterweight Assist |
YES, Yes, YES |
| Country of Origin (Primary) |
US |
| Crankshaft Bolt Hole Quantity |
6, 6, 6 |
| Disc Material |
Organic/Carbon composite, Organic/Carbon composite, Organic/Carbon Composite |
| Disc Type |
Segmented face, Segmented face, Segmented face |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Flywheel Crank Bolt Size |
M11 x 1.50 x 23, 11mm, M11 x 1.50 x 23 |
| Flywheel Crank Flange Register |
2.068, 2.068, 2.068 |
| Flywheel Deck Height |
2.895, 2.895 |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Pressure Plate, Disc, Flywheel, Alignment Tool, Pilot Bearings, & Bolts |
| Input Shaft Diameter |
1-1/8, 1-1/8, 1-1/8 |
| Input Spline Quantity |
26, 26, 26 |
| Installed Height |
2.895, 2.895 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Billet Steel Flywheel / Cast Iron Pressure Plate / Segmented Organic Friction, Billet Steel Flywheel / Cast Iron Pressure Plate / Segmented Organic Friction, Billet Steel Flywheel / Cast Iron Pressure Plate / Segmented Organic Friction |
| Mounting Hardware Included |
Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Outside Diameter |
14.096 |
| Outside Diameter of Friction Surface (Standard) |
12 |
| Pilot Bushing Included |
Yes, Yes |
| Replaceable Friction Surface |
N |
| Ring Gear O.D |
14.096 |
| Ring Gear O.D. |
14.105, 14.105 |
| Ring Gear OD |
14.096 |
| Ring Gear Tooth Count |
168 |
| SDR Required Flag |
N |
| Standard Pack |
1 |
| Tooth Quantity |
168, 168 |
| Torque Capacity |
700, 700 |
| Warranty Time |
12 |
| GTIN |
00788442030853 |
